Beckhoff KL2809 Digital Output Terminal 24VDC

Description:

The Beckhoff KL2809 is a 16-channel digital output bus terminal rated at 24V DC with 0.5A per channel output current, designed for integration into Beckhoff KL series I/O systems in industrial automation and process control applications. With 16 individually switchable outputs mapped across a 16-point terminal block configuration, the KL2809 delivers high-density digital output capability within a single compact DIN rail module, making it an efficient solution for applications requiring a large number of output points within a constrained panel footprint.

Certified to ATEX standard KEMA 10ATEX0075X (II 3G, Ex nA II T4) with an operating temperature range of 0°C to +55°C, the KL2809 is approved for use in Zone 2 hazardous gas environments, making it directly applicable in oil and gas, petrochemical, and offshore automation systems where certified distributed I/O is a project specification requirement.

Industrio.ae supplies Beckhoff KL series digital I/O modules from verified surplus stock, supporting automation engineers, EPC contractors, and MRO procurement teams across the UAE.

Technical Specifications:

• Brand: Beckhoff
• Product Type: 16-Channel Digital Output Bus Terminal
• Part Number: KL2809
• Industry Category: Industrial Automation / PLC I/O Systems / Bus Terminal Modules
• Number of Outputs: 16 x Digital Output
• Output Voltage: 24V DC
• Output Current: 0.5A per channel
• Terminal Points: 16 (Outputs 1–16 with shared +24V and 0V)
• Operating Temperature: 0°C to +55°C
• ATEX Certification: KEMA 10ATEX0075X / II 3G / Ex nA II T4
• Temperature Class: T4
• Hazardous Area Zone: Zone 2 (Gas)
• Standards / Compliance: ATEX (KEMA 10ATEX0075X)
• Serial Number: 25110002
• Mounting Type: 35mm DIN rail (KL series snap-on)
• Origin: Made in Germany
• Other Confirmed Specs: Available upon request

Application:

The Beckhoff KL2809 16-channel digital output terminal is used in high-density I/O applications within Beckhoff KL series bus terminal stations, switching 24V DC field devices including solenoid valves, actuators, relays, and indicator lamps across industrial automation, process control, and machine building environments. Its ATEX Zone 2 certification (Ex nA II T4) qualifies it for direct deployment in hazardous area control panels on oil and gas platforms, petrochemical plants, and offshore installations where certified distributed I/O modules are a mandatory project specification. The high channel count of 16 outputs per module reduces the number of terminals required in large I/O assemblies, lowering panel space requirements and installation cost. This terminal is commonly procured as an MRO replacement or system expansion component by automation engineers and EPC contractors managing Beckhoff-based control architectures in the UAE and internationally.

Automation procurement teams and systems integrators sourcing the Beckhoff KL2809 16-channel digital output terminal with ATEX Zone 2 certification will find verified surplus stock available through Industrio.ae, a UAE-based industrial automation components supplier serving EPC contractors, MRO buyers, and panel builders across Dubai and the Gulf region. As a wholesale and surplus source for Beckhoff KL series high-density digital output modules in the UAE, Industrio.ae supports both single-unit and project-volume procurement of ATEX-certified I/O terminals with competitive availability.

Metafields:

• brand: Beckhoff
• part_number: KL2809
• product_type: 16-Channel Digital Output Bus Terminal
• industry_category: Industrial Automation / PLC I/O Systems / Bus Terminal Modules
• number_of_outputs: 16
• output_voltage: 24V DC
• output_current: 0.5A per channel
• operating_temperature: 0°C to +55°C
• atex_certification: KEMA 10ATEX0075X / II 3G / Ex nA II T4
• temperature_class: T4
• hazardous_area_zone: Zone 2
• standards: ATEX (KEMA 10ATEX0075X)
• serial_number: 25110002
• mounting_type: 35mm DIN rail
• origin: Made in Germany
• condition: Used / Surplus Stock
• stock_quantity_available: Available upon request
• target_market: UAE
• global_shipping: Available upon request

Condition: Used

Tested✅
