Schmersal ZS 236-11Z-M20 Safety Limit Switch IP67

Description:

The Schmersal ZS 236-11Z-M20 safety limit switch supplier demand is driven by machine builders, safety system integrators, and MRO teams specifying certified safety-rated position detection components for industrial machinery guarding and interlocking applications. Manufactured by K.A. Schmersal GmbH & Co. KG, Germany, this plunger-actuated safety limit switch is rated at Ui 500V, Uimp 6kV with a 1NO+1NC (11Z) contact configuration, AC-15 utilisation category, and IP67 environmental protection, making it suitable for demanding industrial environments including wet, dusty, and washdown applications.

Classified as a Safety Component and compliant with IEC 60947-5-1, UL Listed 382E, CSA, and CCC certified, the ZS 236-11Z-M20 meets international safety standards required for machine guarding, door interlocking, and position monitoring on industrial machinery, conveyor systems, and automated production equipment. The M20 cable entry accommodates standard industrial cable glands. Available in UAE through Industrio.ae from surplus and wholesale stock for safety system integrators, machine builders, EPC contractors, and MRO procurement teams. Datasheets and bulk pricing are available upon request.

Technical Specifications:

• Brand: K.A. Schmersal GmbH & Co. KG
• Product Type: Safety Position Limit Switch — Plunger Actuator
• Part Number / Model: ZS 236-11Z-M20
• Internal Reference: 101155262 / 101153775
• Industry Category: Industrial Safety / Machine Guarding / Position Detection
• Insulation Voltage (Ui): 500V
• Impulse Withstand Voltage (Uimp): 6kV
• Contact Configuration: 1NO + 1NC (11Z)
• Utilisation Category: AC-15
• IP Rating: IP67
• Cable Entry: M20
• Actuator Type: Plunger (confirmed visually)
• Housing Material: Thermoplastic (confirmed visually)
• Electrical Ratings: A600 / P150 / Type 1
• Mounting Type: Surface / machine body mount — fixing slots confirmed visually
• Standards / Compliance: IEC 60947-5-1 / CE / UL Listed 382E (IND.CONT.EQ.) / CSA / CCC
• Safety Classification: Safety Component
• Year of Manufacture: 2018
• Other Confirmed Specs: Positive opening mechanism (direct opening action per safety switch classification)

Application:

The Schmersal ZS 236-11Z-M20 is used as a safety-rated position limit switch for machine guarding interlocks, guard door monitoring, end-of-travel position detection, and conveyor system safety circuits in manufacturing plants, packaging machinery, automated assembly lines, and material handling equipment. Its IP67 rating makes it suitable for food processing, pharmaceutical, and outdoor industrial environments where moisture and dust ingress resistance is required.

As a certified Safety Component per IEC 60947-5-1 with UL and CSA listings, this switch is specified for safety-critical applications where reliable positive opening action and documented certification are mandatory for machinery safety compliance. Machine builders, safety system integrators, and MRO procurement teams managing certified safety switch inventories across the UAE can source this Schmersal component through Industrio.ae's wholesale and surplus industrial parts network.

Schmersal ZS 236-11Z-M20 safety limit switch is available through Industrio.ae, a UAE-based distributor of industrial safety and machine guarding components serving machine builders, safety system integrators, EPC contractors, and MRO procurement teams across Dubai and the wider GCC region. Buyers sourcing Schmersal safety limit switches in wholesale quantities or for active machinery safety compliance and maintenance requirements can contact Industrio.ae directly for pricing and availability confirmation.

Metafields:

• brand: K.A. Schmersal GmbH & Co. KG
• part_number: ZS 236-11Z-M20
• internal_reference: 101155262 / 101153775
• product_type: Safety Position Limit Switch — Plunger Actuator
• industry_category: Industrial Safety / Machine Guarding / Position Detection
• voltage_rating: Ui 500V
• impulse_withstand_voltage: Uimp 6kV
• current_rating: A600 / P150
• contact_configuration: 1NO + 1NC (11Z)
• utilisation_category: AC-15
• ip_rating: IP67
• cable_entry: M20
• power_rating: Available upon request
• input_voltage: Available upon request
• output_voltage: Not applicable
• mounting_type: Surface / Machine Body Mount
• standards: IEC 60947-5-1 / CE / UL Listed 382E / CSA / CCC
• year_of_manufacture: 2018
• condition: Available upon request
• stock_quantity_available: Available upon request
• target_market: UAE
• global_shipping: Available upon request

Condition: New Open Box
