Schneider Electric RXG 24VDC Relay With Socket RGZE1S48M 5A 250V

Description:

The Schneider Electric RXG miniature plugin relay with RGZE1S48M DIN rail socket is a complete relay assembly from the Zelio RXG range, rated at 24V DC coil voltage with a 5A / 250V contact rating on the socket. The relay features a built-in LED coil status indicator and a green push-to-test manual override button, supporting fast commissioning and in-panel diagnostics without the need for external tooling.

The 1CO (1 changeover) contact configuration provides both normally open and normally closed switching paths, making this relay assembly suitable for a wide range of control, interlocking, and signal switching applications in industrial automation, building management, and machine control panels. The RGZE1S48M socket provides secure DIN rail mounting with screw terminal connections for reliable field wiring integration.

Certified to CE, UKCA, EAC, cULus, and CSA standards, this Telemecanique relay assembly is widely specified by panel builders and automation engineers. Industrio.ae supplies Schneider Electric relay modules from verified surplus stock to procurement teams and MRO buyers across the UAE.

Technical Specifications:

• Brand: Schneider Electric (Telemecanique)
• Relay Part Number: RXG series — 24VDC coil (full suffix available upon request)
• Socket Part Number: RGZE1S48M
• Product Type: Miniature Plugin Relay + DIN Rail Socket Assembly
• Industry Category: Industrial Automation / Relay Modules / Panel Building / Control Systems
• Coil Voltage: 24V DC
• Contact Voltage Rating: 250V
• Contact Current Rating: 5A
• Contact Configuration: 1CO (1 changeover — NO + NC)
• LED Indicator: Yes
• Manual Override: Yes (push-to-test button)
• Socket Mounting: 35mm DIN rail
• Standards / Compliance: CE / UKCA / EAC / cULus / CSA
• Sub-brand: Telemecanique
• Origin: Made in China
• Other Confirmed Specs: Available upon request

Application:

The Schneider Electric RXG relay with RGZE1S48M socket is used in industrial control panels, PLC output interfaces, building automation systems, and machine control cabinets where compact, DIN rail-mounted relay switching is required at 24V DC coil voltage. Its 1CO contact configuration supports interlocking, signal routing, and load switching functions in automation and process control applications. The push-to-test override button allows engineers to manually actuate the relay during commissioning or fault-finding without energising the coil circuit. This relay assembly is regularly procured as an MRO replacement or panel build component by automation engineers, panel builders, and electrical procurement teams across industrial sectors in the UAE and Gulf region.

Automation procurement teams and panel builders sourcing the Schneider Electric RXG 24VDC miniature relay with RGZE1S48M DIN rail socket will find verified surplus stock available through Industrio.ae, a UAE-based industrial automation and electrical components supplier serving EPC contractors, MRO buyers, and systems integrators across Dubai and the broader Gulf region. As a wholesale source for Schneider Electric Zelio RXG relay modules and Telemecanique control components in the UAE, Industrio.ae supports both single-unit and bulk procurement with competitive stock availability.

Metafields:

• brand: Schneider Electric (Telemecanique)
• relay_part_number: RXG series 24VDC
• socket_part_number: RGZE1S48M
• product_type: Miniature Plugin Relay + DIN Rail Socket Assembly
• industry_category: Industrial Automation / Relay Modules / Panel Building / Control Systems
• coil_voltage: 24V DC
• contact_voltage_rating: 250V
• contact_current_rating: 5A
• contact_configuration: 1CO (NO + NC)
• led_indicator: Yes
• manual_override: Yes (push-to-test)
• socket_mounting: 35mm DIN rail
• standards: CE / UKCA / EAC / cULus / CSA
• origin: Made in China
• condition: Used / Surplus Stock
• stock_quantity_available: Available upon request
• target_market: UAE
• global_shipping: Available upon request

Condition: New Open Box
